CONTEMPORARY – FOR PUBLIC AREAS
Pedestal Mounted Overhead Braced / Headrail Cubicle Partitioning Systems
Available in 13mm Compact Laminate and 18mm / 32mm MR Board.
Suitable for Toilet & Showers Partitions. Shower partitions available in 13mm Compact Laminate only.
Perfect for Schools, Community Centres, Leisure Centres & Commercial applications.
SPECIFICATIONS
Overall Depth
1500mm to 1800mm
Divisional Panels
1700mm high, 205mm floor clearance
Frontal Panels
2027mm high including a 205mm floor clearance,
minimum width 150mm
Doors
1700mm high x 600mm wide
with a 205mm floor clearance
Headrail
Clear anodised aluminium round headrail
Pedestal
Clear anodised aluminium foot
Wall Channels
Clear anodised aluminium U channel
OPTIONS
Rebated Doors
Privacy profile option available
Powder Coating Option Available
To match board colour
Pedestal
Clear anodised aluminium foot, black nylon base
AQUASERIES DOOR HARDWARE
Clear Anodised Aluminium, Satin Finish
Black Enamel Coated, Satin Finish
PRODUCT SHOWCASE
Project: Balga Community Centre, Perth WA
Doors: Laminex Oyster Grey
Frontals: Maica 3 Degree Cool
IPS: Maica 3 Degree Cool
Custom: Clear anodised aluminium foot with black nylon base
Project: Balga Community Centre, Perth WA
Doors: Laminex Oyster Grey
Frontals: Maica 3 Degree Cool
IPS: Maica 3 Degree Cool
Custom: Clear anodised aluminium foot with black nylon base
Project: Optus Stadium, Perth WA
Doors: Laminex Polar White
Frontals: Laminex Black
Custom: Clear anodised aluminium foot with black nylon base
Project: Optus Stadium, Perth WA
Doors: Laminex Polar White
Frontals: Laminex Black
Custom: Clear anodised aluminium foot with black nylon base
Project: Butler Reserve Clubroom, Scarborough Perth WA
Doors: Maica Caldo Red
Frontals: Maica Charcoal Grey
Custom: Powder Coated Black Extrusions
Door Hardware: Aqua Series Satin Matte Black
Project: Butler Reserve Clubroom, Scarborough Perth WA
Doors: Maica Caldo Red
Frontals: Maica Charcoal Grey
Custom: Powder Coated Black Extrusions
Door Hardware: Aqua Series Satin Matte Black
Project: The Galway Hooker, Scarborough Perth
Doors: Laminex Natural Walnut
Frontals: Laminex Natural Walnut
Custom: Routed Panels
Door Hardware Aqua Series Satin Chrome
Project: The Galway Hooker, Scarborough Perth
Doors: Laminex Natural Walnut
Frontals: Laminex Natural Walnut
Custom: Routed Panels
Door Hardware Aqua Series Satin Chrome
Project: The Galway Hooker, Scarborough Perth
Doors: Laminex Natural Walnut
Frontals: Laminex Natural Walnut
Custom: Routed Panels
Door Hardware Aqua Series Satin Chrome
Project: ARC Cockburn Perth WA
Doors: Maica Warn White
Frontals: Maica Warn White
Custom: Clear anodised aluminium foot with black nylon base
Project: ARC Cockburn Perth WA
Doors: Maica Warn White
Frontals: Maica Warn White
Custom: Clear anodised aluminium foot with black nylon base
Project: Balga Community Centre, Perth WA
Doors: Laminex Oyster Grey
Frontals: Maica 3 Degree Cool
IPS: Maica 3 Degree Cool
Custom: Clear anodised aluminium foot with black nylon base
DOWNLOADS
Aqualoo cubicle partitioning systems are low maintenance, water, impact, graffiti resistant and fire retardant.
Compact laminate cubicle partitioning systems meet Group 3 Classification (in accordance with AS 5637.1-2015).
A family owned company, WCCI has been in operation since 2000 with distributors in SA, NSW, VIC and QLD – Aqualoo offer supply and install or offer flat pack options Australia Wide.
